The QY Insulated Overhead Crane is a type of lifting equipment designed for specific industrial applications. It is primarily used in the smelting workshops of non-ferrous metals such as aluminum, magnesium, lead, and zinc electrolysis. During operation, the insulation device effectively prevents the current from being conducted from the suspended charged components to the crane body, ensuring operational safety. The crane's critical parts use high-performance insulating materials such as Glass Fiber Reinforced Plastic (GFRP). Additionally, one or more layers of insulating paint are applied to the metal structure's surface to form an insulation protection layer.
In aluminum electrolysis workshops, where temperatures are typically high, the insulated overhead crane safely handles anodes, cathodes, and semi-finished aluminum materials under high temperature and high humidity conditions.
The insulated overhead crane is suitable for the smelting processes of non-ferrous metals such as magnesium, lead, and zinc. These environments are harsh, with corrosive gases (e.g., sulfuric acid), toxic and harmful gases (e.g., hydrogen fluoride), as well as high currents and strong magnetic fields.
In processes such as aluminum ingot casting, extrusion, and rolling, the crane moves raw materials, intermediate products, and finished products.
In specific power facilities, such as substations or power plants, the insulated overhead crane can perform maintenance and repair tasks. Particularly for high-voltage electrical equipment, insulation prevents current from being conducted through the suspended components to the crane, thus avoiding potential hazards.
Specifically designed for material handling tasks in environments with high currents or strong magnetic fields. It uses multi-stage insulation technology (typically three levels of insulation) to effectively prevent the transmission of electrical current to operators or other parts of the equipment.
Made with special materials and coatings that provide excellent corrosion resistance, enabling long-term stable operation regardless of harsh environmental conditions. This enhances the equipment's lifespan and reduces maintenance costs.
The crane features advanced control systems, including variable frequency speed control, precise positioning, and other functionalities that ensure smooth and accurate operation. Additionally, its design fully considers work efficiency, with features such as fast lifting speeds and efficient braking systems, which can significantly boost production efficiency. Some high-end models may also integrate intelligent diagnostic systems, allowing users to monitor equipment status in real-time and receive early warnings of potential faults, ensuring continuous and stable production.
This is the specification table for a 20ton lifting capacity crane. We also offer customized cranes with different lifting capacities. Feel free to contact us for more information!
| apacity | Main | ton | 20 | |||||||||||||||
| Aux. | 5 | |||||||||||||||||
| Span | meter | 10.5 | 13.5 | 16.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | 10.5 | 13.5 | 16.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | |
Lifting Height | Main | 12 | 12 | |||||||||||||||
| Aux. | 14 | 14 | ||||||||||||||||
| Work Duty | A5 | A6 | ||||||||||||||||
Speed | Main | m/min | 7.2 | 9.7 | ||||||||||||||
| Aux. | 12.7 | |||||||||||||||||
| Trolley traveling | 44.6 | |||||||||||||||||
| Crane traveling | 84.7 | 112.5 | 87.6 | 101.4 | ||||||||||||||
| Max.wheel loading | kN | 162 | 169 | 178 | 191 | 199 | 211 | 222 | 231 | 167 | 174 | 183 | 197 | 205 | 218 | 229 | 238 | |
| Power supply | 3-Phase A.C. 50HZ 380V | |||||||||||||||||
